Building a small circuit board? You need parts that fit tight spaces but pack power. The smd 4 x 5.4mm electrolytic capacitor lcsc electronics easyeda does just that. This tiny component stores energy and smooths power in your projects. Hobbyists grab it for DIY gadgets. Engineers use it in pro designs. Source it easy from LCSC. Design it quickly in EasyEDA. In 2025, it’s a must for compact tech. Let’s break it down step by step.
What Is an SMD 4 x 5.4mm Electrolytic Capacitor? Basics for Beginners
Start here. An electrolytic capacitor uses a special liquid inside to hold lots of charge. Unlike flat ceramic ones, it gives high values in a small spot. The “SMD” means surface-mount device. It sticks right on your PCB—no holes needed. The size? 4mm wide by 5.4mm tall. Perfect for packed boards.
Why pick this one? It handles DC power bumps. Think smoothing voltage after a rectifier. Or blocking noise near chips. Aluminum makes the core. An oxide layer acts as the barrier. It’s polarized—positive and negative ends matter a lot.
History quick: Electrolytic caps date to 1896. Charles Pollak invented them for AC to DC fixes. SMD versions boomed in the 1980s with tiny electronics. Today, makers like you use them in drones or wearables.
Factual note: Tolerance runs ±20%. That means if you spec 47µF, it might hit 37.6 to 56.4µF. Always check datasheets.
For a deeper spec look, see this 20V 1000µF example.
Key Specs: What Makes This Capacitor Tick
Numbers matter in design. Here’s the rundown for a typical smd 4 x 5.4mm electrolytic capacitor lcsc electronics easyeda apart. Values vary by maker, but these are common.
- Capacitance Range: 1µF to 100µF. Higher needs more space, so 47µF fits best here.
- Voltage Rating: 6.3V to 50V. Pick 2x your circuit’s max for safety.
- ESR (Equivalent Series Resistance): Under 1Ω. Low ESR means less heat and better speed.
- Ripple Current: Up to 200mA RMS. Good for power filters.
- Temp Range: -40°C to +105°C. Tough for hot spots.
- Lifetime: 1000 to 2000 hours at max temp. Derate voltage to double life.
Example: Honor Elec RVT1H100M0505 hits 10µF at 50V. Costs $0.034. Stock? Thousands at LCSC.
Stats show: SMD electrolytics cut board space by 50% vs through-hole. Market grows 5% yearly to 2028, per reports.
Tip: Always derate. Run at 70% voltage. Boosts life 50%.
Compared to ceramics: These handle low freq bulk storage. Ceramics zap high-freq noise. Use both.
Why Choose SMD 4 x 5.4mm? Pros for Your Projects
Space tight? This cap shines. It mounts flat, saves height. Automated machines love it—no hand soldering mess.
Pros list:
- Compact Fit: 4×5.4mm squeezes into IoT boards or portables.
- High Density: Packs µF where others can’t.
- Cost Low: Pennies per unit. Bulk from LCSC? Even better.
- Reliable: Oxide dielectric holds steady if placed right.
- Easy Source: LCSC stocks tons. EasyEDA links directly.
Downsides? Polarized—flip it, and boom. Heat sensitive too. Keep under 105°C.
Real win: A student drone project. Used these for power smoothing. The board shrank 20%. Flight time up.
For KiCad users, check footprint tips.
Meet LCSC Electronics: Your Trusted Source for Components
LCSC leads in Asia for parts. Founded in 2011, it’s JLCPCB’s sister. Over 600,000 items. Ships global.
Why is LCSC for smd 4 x 5.4mm electrolytic capacitor lcsc electronics easyeda? Huge stock. Searching “D4xL5.4 electrolytic” yields hits like Capxon HV101M016E055ETR—100µF 16V for $0.053.
Filters rock: By size, voltage, maker. Datasheets free. MOQ? One piece ok for protos.
Stats: 16,000 orders daily. 99% on-time ship. ISO certified.
Pro tip: Use LCSC-Reels for small batches. Feeds pick-place machines easily.
Link to their capacitor category for quick browse.
EasyEDA: Design Your PCB with One-Click Sourcing
EasyEDA pairs perfectly with LCSC. Free online tool for schematics and layouts. Drag-drop parts.
How it works with this cap:
- Search LCSC library: Type smd 4 x 5.4mm electrolytic capacitor lcsc electronics easyeda.
- Grab symbol and footprint: Pre-made, 3D views too.
- Drop on board: Auto-routes if you want.
- BOM export: Orders straight to LCSC.
Achievements: Millions of users. JLCPCB fabs your board at the same time.
Example: Hobby maker builds audio amp. Adds cap for filter. One click sources 100 units. Done in days.
For workflow boosts, see PCB design tools.
Who Needs This Capacitor Most?
You fit if you’re hands-on with circuits. Hobbyists tinker on weekends. Students learn in class. Makers prototype ideas.
- Hobbyists and Makers: DIY robots or LED lights. This cap fits tiny enclosures.
- Students: School projects on Arduino. Cheap and available.
- Engineers: Embedded pros in IoT. Compact for wearables.
- Small Manufacturers: Assembly lines. Standard size speeds production.
Stats: 70% hobbyists use SMD for space. EasyEDA users? Up 30% yearly.
Quote: “Switched to SMD electrolytics—my board’s half size now.” – Maker forum post.
For education ties, explore learning platforms.
Real Applications: Where This Cap Shines in Circuits
Put it to work. Top spots:
- Power Supply Filtering: After rectifier. Smooth ripple. Use 100µF near the regulator.
- Decoupling: By ICs. Blocks noise. Pair with 0.1µF ceramic.
- Audio Circuits: Coupling stages. Removes DC offset.
- Battery Backup: Holds charge brief. For RTCs.
- Motor Drivers: Stabilizes voltage spikes.
Example: Portable sensor. 47µF 16V cap filters 3.3V line. Noise down 40%. The battery lasts longer.
In wearables: Health tracker. Fits under the skin patch. Monitors steady.
Wikipedia notes: Electrolytics for bulk, others for speed.
For sensor ideas, check tech for machines.
Step-by-Step: Sourcing from LCSC Electronics
Grab yours easily. Follow this:
- Hit LCSC Site: Go to lcsc.com. Search “SMD electrolytic 4×5.4”.
- Filter Specs: Pick voltage, cap value. Sort by price.
- Check Stock: Green means ready. Datasheet link.
- Add to Cart: One or reel. Promo codes often.
- Checkout: PayPal or card. Ships in 3 days.
- Track Order: App alerts.
Cost? $0.02-$0.10 each. Bulk drops more.
Tip: Quote tool for customs. Saves headaches.
Integrating in EasyEDA: Design Like a Pro
Design flow:
- Open EasyEDA: New project. Schematic tab.
- Search Library: Type smd 4 x 5.4mm electrolytic capacitor lcsc electronics easyeda.
- Place Symbol: Drag to sheet. Wire up.
- Footprint Assign: PCB tab. Match D4xL5.4.
- Route and Check: DRC run. Fix errors.
- Order BOM: Sync to LCSC. Fab with JLCPCB.
Saves 10-15 hours per board, per studies.
For KiCad fans, import LCSC models. See model guide.
Handling Challenges: Tips for Success and Fixes
Watch these:
- Polarity Flip: Stripe marks negative. Wrong way? Cap fails fast.
- Heat Damage: Solder quick. Reflow under 260°C.
- Derating Miss: Use 1.5x voltage. Life jumps.
- ESR High: Pick low-ESR for switchers.
Fix list:
- Test with meter post-solder.
- Add vents if hot.
- Parallel for more cap.
Stats: 20% failures from polarity. Avoid marks.
For troubleshooting, try error fixes.
Comparisons: This Cap vs Others
Quick table:
| Feature | SMD 4×5.4 Electrolytic | Ceramic 0805 | Tantalum B Case |
| Cap Range | 1-100µF | 0.1-10µF | 1-100µF |
| Size | 4×5.4mm | 2×1.25mm | 3.5×2.8mm |
| Cost | $0.03 | $0.01 | $0.20 |
| Best For | Bulk filter | High freq | Stable low ESR |
| Polarized? | Yes | No | Yes |
Wins on value for bulk needs.
For alternatives, see component picks.
Future Trends: SMD Caps in 2025 and Beyond
Miniaturization rules. Expect polymer hybrids—lower ESR, longer life. Market? $20B by 2030.
EasyEDA adds AI routing. LCSC stocks more green parts1.
Tip: Watch for 105°C+ rated. Better for EVs.
Quote: “SMD electrolytics evolve fast—2025 brings 20% smaller.” – Industry report.
Explore tech trends.
Why the SMD 4 x 5.4mm Electrolytic Capacitor LCSC Electronics EasyEDA Combo Wins for Makers
Here’s your H2 hit with smd 4 x 5.4mm electrolytic capacitor lcsc electronics easyeda. This pair streamlines everything. Design, source, build—one flow. Hobbyists save time. Engineers cut costs. In 2025, it’s the blueprint for success.
Advanced Tips: Level Up Your Builds
Go pro:
- Simulate in EasyEDA: Check ripple before build2.
- Bulk Buy: LCSC discounts at 100+.
- Custom Footprints: Tweak for odd boards.
- Test Rigs: Bench power for endurance.
Example: Engineer prototypes smartwatch. Caps filter battery dips. Device slims 15%.
For coding ties, see Python tools.
Case Studies: Real Projects with This Cap
Story one: Student LED driver. 10µF 25V smooth pulses. The board fits the palm.
Story two: Maker IoT sensor. 47µF decouples ESP32. Uptime 99%.
Stats: Projects with SMD run 30% cooler.
Maintenance and Longevity: Keep It Going
Store dry. Solder clean. Monitor heat in use.
Replace every 5 years in hot apps.
FAQs About SMD 4 x 5.4mm Electrolytic Capacitor LCSC Electronics EasyEDA
What exactly is the SMD 4 x 5.4mm electrolytic capacitor?
It’s a tiny surface-mount aluminum electrolytic capacitor (4 mm diameter × 5.4 mm height) perfect for tight PCB layouts. It stores energy and smooths power in circuits.
Why choose the 4 x 5.4mm size over bigger ones?
This size saves space, works great in compact gadgets (drones, wearables, IoT sensors), and fits automated assembly machines perfectly.
Where is the best place to buy SMD 4 x 5.4mm electrolytic capacitors?
LCSC Electronics is the top choice. They stock thousands of values, offer low prices (often $0.02–$0.08 each), and ship worldwide fast.
Can I use this capacitor with EasyEDA?
Yes! EasyEDA has ready-made symbols and footprints for the smd 4 x 5.4mm electrolytic capacitor lcsc electronics easyeda. One click adds it and orders directly from LCSC.
What are the most common capacitance and voltage ratings for this size?
Popular options are 10 µF, 22 µF, 47 µF, and 100 µF at 6.3 V, 10 V, 16 V, 25 V, and 35 V. 47 µF 16 V is a hobbyist favorite.
Wrapping Up: Power Your Projects Right
The smd 4 x 5.4mm electrolytic capacitor lcsc electronics easyeda delivers big in small packages3. From hobby hacks to pro embeds, it smooths paths. Source smart from LCSC. Design fast in EasyEDA. Build reliable circuits today.
What’s your next project with this cap?
